Range Frames

Source: R/geom-rangeframe.R
geom_rangeframe.Rd

Axis lines which extend to the maximum and minimum of the plotted data.

Usage

geom_rangeframe(
  mapping = NULL,
  data = NULL,
  stat = "identity",
  position = "identity",
  ...,
  sides = "bl",
  na.rm = FALSE,
  show.legend = NA,
  inherit.aes = TRUE
)

Arguments

mapping

Set of aesthetic mappings created by aes(). If specified and inherit.aes = TRUE (the default), it is combined with the default mapping at the top level of the plot. You must supply mapping if there is no plot mapping.

data

The data to be displayed in this layer. There are three options:

If NULL, the default, the data is inherited from the plot data as specified in the call to ggplot().

A data.frame, or other object, will override the plot data. All objects will be fortified to produce a data frame. See fortify() for which variables will be created.

A function will be called with a single argument, the plot data. The return value must be a data.frame, and will be used as the layer data. A function can be created from a formula (e.g. ~ head(.x, 10)).

stat

The statistical transformation to use on the data for this layer, either as a ggproto Geom subclass or as a string naming the stat stripped of the stat_ prefix (e.g. "count" rather than "stat_count")

position

Position adjustment, either as a string naming the adjustment (e.g. "jitter" to use position_jitter), or the result of a call to a position adjustment function. Use the latter if you need to change the settings of the adjustment.

...

Other arguments passed on to layer(). These are often aesthetics, used to set an aesthetic to a fixed value, like colour = "red" or size = 3. They may also be parameters to the paired geom/stat.

sides

A string that controls which sides of the plot the frames appear on. It can be set to a string containing any of 'trbl', for top, right, bottom, and left.

na.rm

If FALSE, the default, missing values are removed with a warning. If TRUE, missing values are silently removed.

show.legend

logical. Should this layer be included in the legends? NA, the default, includes if any aesthetics are mapped. FALSE never includes, and TRUE always includes. It can also be a named logical vector to finely select the aesthetics to display.

inherit.aes

If FALSE, overrides the default aesthetics, rather than combining with them. This is most useful for helper functions that define both data and aesthetics and shouldn't inherit behaviour from the default plot specification, e.g. borders().

Details

This should be used with `coord_cartesian(clip="off")` in order to correctly draw the lines.

Aesthetics

  • colour

  • size

  • linetype

  • alpha

References

Tufte, Edward R. (2001) The Visual Display of Quantitative Information, Chapter 6.

See also

Other geom tufte: geom_tufteboxplot()

Examples

library("ggplot2")

ggplot(mtcars, aes(wt, mpg)) +
  geom_point() +
  geom_rangeframe() +
  coord_cartesian(clip = "off") +
  theme_tufte()


# In the example above,
# `coord_cartesian(clip="off")`` ensures that the full width of the line is drawn.
# if you know a better way to fix this,
# please open an issue or PR on github https://github.com/jrnold/ggthemes/issue
